MPPT Hybrid Solar Inverter 1kva 3kva 5kva, with UPS function, Parallel function optional

Product Categories

Smart Water Meter [10]
Smart Home [48]
Solar Energy [43]

YIWU DOWLER IMPORT AND EXPORT COMPANY

Contact Now

MPPT Hybrid Solar Inverter 1kva 3kva 5kva, with UPS function, Parallel function optional

Name: MPPT Hybrid Solar Inverter 1kva 3kva 5kva with UPS function Parallel function optional
Brand: OEM Acceptable
Price: 278.30 USD

Quality MPPT Hybrid Solar Inverter 1kva 3kva 5kva, with UPS function, Parallel function optional wholesale

Place of Origin : Wenzhou

Brand Name : OEM Acceptable

Model Number : NVP3K-50

Supply Ability : 1000 Piece/Pieces per Week

Price : $278.30 - $314.50/Pieces

Input Voltage : 12V 24V 48VDC

Output Voltage : 230VAC

Output Frequency : 50HZ OR 60HZ

Output Type : Single

Size : 430*350*198mm

Type : DC/AC Inverters

Inverter Efficiency : 98%

Certificate : ce fcc rohs IOS9001

Warranty : 12 months

Weight : 8KG

Rated Power : 3000VA

Peak Power (5s) : 6000VA

Transfer Time : 10ms (For personal computers), 20ms (For home Appliances)

PV Input Voltage Range : 145VDC

Parallel function : (Optional) max 6 pcs

Built-in MPPT Controller : 60A

Port : NIngbo

Contact Now

MPPT Hybrid Solar Inverter 1kva 3kva 5kv with UPS function

- Pure sine wave inverter with built-in MPPT solar charge controller

- User-friendly LCD display, Cold start function

- With Charger. Solar or Public power priority adjustable by LCD

- Charging current, float charging voltage etc are adjustable by LCD

- Input voltage range adjustable according to different applications

- Auto restart when AC is recovering

- Protection: overload, short circuit etc

- Suits to fan, TV, PC, microwave oven, water pump etc

- Parallel function is optional, max 6 pcs

Model		NVMP1K-25	NVMP3K-25	NVMP3K-60		NVMP5K-60	NVMP5K-80
Rated Power		1000VA (800W)	3000VA (2400W)			5000VA (4000W)
Output	Peak Power	2000VA	6000VA			10000VA
	Waveform	Pure sine wave
	AC Voltage Regulation	(Battery mode) 230VAC ± 5%
	Efficiency	90-93%	93%
	Transfer Time	10ms (For personal computers), 20ms (For home Appliances)
	No Load Power Comp.	<25W				<50W
	Saving Mode Power Comp.	<10W				<15W
AC Input	Voltage/Frequency	230VAC, 50/60Hz Auto recognition
	Voltage Range	170-280VAC (For personal computers) 90-280VAC (For home Appliances)
	Max. Charge Current	Utility 10A or 20A adjustable	Utility 20A or 30A adjustable			Utility 20-60A adjustable Utility+PV 20-120A adjustable
Solar Charge Controller	Max. Charging Current	MPPT 25A	MPPT 25A	MPPT 60A		MPPT 60A	MPPT 80A
	Max Efficiency	98%
	PV Input Voltage Range	30-66VDC	30-66VDC	60-115VDC		60-115VDC
	Max PV Array Power	600W	600W	1500W		3000W
	Max. PV Input	75VDC	75VDC	145VDC		145VDC
	Standby Consumption	2W
Battery	Battery Voltage	24VDC	24VDC			48VDC
	Floating Charge Voltage	27VDC	27VDC			54VDC
	Overcharge Protection	31VDC	31VDC			60VDC
Humidity		5%-95% Relative Humidity (Non-condensing)
Operating Temperature		Operating 0℃ - 55℃ Storage -15℃ - 60℃
Parallel Function (Optional)		/				Max parallel 6pcs
Product Size		272355128mm		295540140mm
Product Weight		7.4KG	8KG	10KG	13.5KG
Packing Size/Weight		1 pc/ctn, 349433235mm, 9KG	1 pc/ctn, 349433235mm, 9.3KG	1 pc/ctn, 355530200mm, 11.3KG	1 pc/ctn, 390608246mm, 14.8KG
Recommendation for Panel Configuration		500W 250W*2pcs	500W 250W*2pcs	1500W 250W*6pcs	3000W 250W*12pcs

MPPT Hybrid Solar Inverter 1kva 3kva 5kva, with UPS function, Parallel function optional

FAQ

Q3.What’s the payment term?

A:For sample order,100% payment before shipment

For bulk order,T/T 30% deposit and 70% balance before shipment or against copy of B/L.

Q4.What’s the delivery time?

A:For sample,within 3-5 days after receiving payment.

For bulk order,usually in 10-15 days after receiving payment.

Q5.What’s certification you got?

A:We have certification of ISO9001,CE,RoHS,FCC,ETL,TUV,UL.

Q6.What’s the standard of package?

A:For small capacity,we packed with carton,but for big capacity,we can make the pallet or use strong

wooden case to distinguish and protect the goods.

Q7.Could you offer C/O?

A:Yes.We can prepare relative documents to foreign affairs office or other office to apply for this

certificate.We also supply Form A,Form B,Form E,Form F and CIQ for Egypt.

Q8.What will your company do for the warranty?

A:All the goods are 100% quality testing before shipping.We’ll offer 12 or 18 month warranty.During the

warranty period,if goods have any quality problem,we’ll send parts for your repair and replace.If goods

are damaged by personal,we are not responsible.

Q9.Does your company offer technical support?

A:We have a professinal technical support group for all the item selling.If you need any assistance on your item problem,please do not hesitate to contact us,our technical support will be there to assist you.

MPPT Hybrid Solar Inverter 1kva 3kva 5kva, with UPS function, Parallel function optional Images
