1 Pair Set MC 4 Solar Panel Cable Connector Male+Female Copper Pins Tin plated, IP 68 30A TUV High Quality DIY

Name: 1 Pair Set MC 4 Solar Panel Cable Connector MaleFemale Copper Pins Tin plated IP 68 30A TUV High Quality DIY
Brand: DOWLER
Price: 0.70 USD

Quality 1 Pair Set MC 4 Solar Panel Cable Connector Male+Female Copper Pins Tin plated, IP 68 30A TUV High Quality DIY wholesale

Model Number : NVST4-21

Place of Origin : zhejiang

Packaging Details : carton

Price : $0.70/Pairs 1-999 Pairs

Brand Name : DOWLER

Type : MC 4 Solar Cable Connector

Brand : NOVA

Application : Solar Installation

Color : Black

Material : Copper, tin plated

Cable standard : 4 - 6 mm2

Rate voltage : DC 1500V or 1000V

Rated current : 30A

Contact presistance : ≤0.25mΩ

Waterproof grade : IP 68 (1m, 1h)

Ambient Temperature : -40℃~+85℃

Flame retardant grade : UL94 V-0

Insulation material : PPO/PA

OEM : Acceptable

Certificate : TUV, ISO 9001

Contact Now

Product Paramenters

MC 4 Cable Connector (Locking type)	Composite contact material: Copper, tin plated Rated current: 30A Contact presistance: ≤0.25mΩ Waterproof grade: IP 68 (1m, 1h) Ambient Temperature: -40℃～+85℃ Flame retardant grade: UL94 V-0 Insulation material: PPO/PA Salt mist spray test, degree of severity 6: IEC 60068-2-52
NVST4-22	Cable standard: 2.5 - 4 mm2 Rate voltage: DC 1500V
NVST4-21	Cable standard: 4 - 6 mm2 Rate voltage: DC 1500V
NVST4-12	Cable standard: 2.5 - 4 mm2 Rate voltage: DC 1000V
NVST4-11	Cable standard: 4 - 6 mm2 Rate voltage: DC 1000V

Details Images

1 Pair Set MC 4 Solar Panel Cable Connector Male+Female Copper Pins Tin plated, IP 68 30A TUV High Quality DIY

Recommend Products

Our Advantages

We DOWLER are an innovative and R&D factory with more than 20 patents, being awarded as the national innovative technology and high-tech enterprise.

Our products are high quality with many International certifications like ISO9001, CE, RoHS, FCC, ETL and TUV.

We are positive to attend many exhibitions all over the world such as Intersolar in Munich and HK Electronics etc.

Our advantages:

1. Reliable raw materials applied. 2. 100% test on each semi-finished pcb and final-finished product, ensure performance. 3. Five steps quality control management.

4. R&D team offer you technical support. 5. One year warranty: replacement or free spare parts

6. Swift reply within 8 hours 7. Fast delivery: 3-15 workdays as per quantity

8. Customer oriented, specialized service according to different demand

Welcome inquiry:

* DC-AC Inverter 300-5000W

* UPS Inverter/Charger 1-12KW

* Hybrid Inverter with built-in PWM/MPPT Controller

* PWM/MPPT Solar Controller 10-120A

* Solar/Grid ATS

* MC4 Connectors/Tools

* Battery Charger

1 Pair Set MC 4 Solar Panel Cable Connector Male+Female Copper Pins Tin plated, IP 68 30A TUV High Quality DIY Images
